Name: PTFE Welding Release Fabrics
Brand: SKYFLON
SKU: 00102
Availability: InStock
Rating: 5 (1 reviews)

Home > PTFE Coated Fiberglass Fabrics > PTFE Welding Fabrics

Description

PTFE Welding & Release Fabrics

Skyflon developed PTFE release fabrics sepically for PVC window & door welding & mould release. Our release fabrics provide a long lasting, non stick surface with excellent chemical resistance. The high release properties of our products prevent the molten PVC from sticking to the metal. The excellent value for thermal transfer are a guarantee for optimal welding results.

Therefore, our ptfe release fabrics are widly used as a release medium for PVC window & door welding equipment covering the high temp platens that weld the corners of the PVC window & door extrusion together.

Release fabrics are widly used as a release medium for PVC window & door welding equipment covering the high temp platens that weld the corners of the PVC window & door extrusion together.

Feature

Extremes of heat and cold resistance: minus -73℃ to plus +260℃
High release from sticky materials ‘non-stick’
Easy cleaning (Nothing bonds permanently
Low friction co-efficient
Ultra-violet,infra-red,microwave,radio frequency resistance
Non-combustible – seld extinguishing
Chemical corrosion and moisture resistance
Low thermal expansion
Mildew and fungus resistance

Specification

Model	Color	Standard Width(mm)	Total Thickness(mm)	Weight(g/m2)	Tensiles(N/5cm)
013-270 WD Gold	Gold	1000 - 1500	0.13	270	1200
013-270 WD Blue	Blue	1000 - 1500	0.13	270	1200
015-320 WD Gold	Gold	1000 - 1500	0.15	320	1500
015-320 WD Blue	Blue	1000 - 1500	0.15	320	1500
