The open mesh PTFE impregnated glass fiber belt can be supplied in brown,blue or black U.V. barrier coating for UV drying. Width of up to 5000mm wide, the fluorocarbon resin used in the curing process is chemically inert, woven glass substrate provides excellent strength and dimensional stability.The mesh belt is used for screen printing, and the imprinting material is conveyed through the drying furnace and the cooling chamber. These belts are durable and perform well at a wide range of operating temperatures.Zobon has Has developed a full range of open mesh belt products for belt dryers.These belts can be used for textile,food,screen printing,,packaging, electronics, and other industries

Properties

• Lightweight and energy efficiency for economical operation

• Outstanding temperature resistance (-170^oC + 260^oC)

• Low thermal mass

• Controlled porosity

• Superior non-stick surface,easy to clean

• Exceptional strength and dimensional stability

• Superior tracking

To assure the best performance and accurate tracking, we recommend that wherever possible, conveyor belts be ordered with splices. We offer all the standard splices. Please call our technical service department to discuss which splice would be best for your specific application.

• Overlap splice

• Butt splice

• Alligator/Clipping splice

• Castellated Splice

• Bullnose Splice

To enhance the tracking and belt life, Zobon offers three styles of edging:

•  PTFE Film - PTFE film encapsulates the edge the help stop fraying and offer protection. The benefit to using film is that it is soft in nature and will stretch with the belt when under tension.

•  PTFE Coated Fiberglass - PTFE coated fiberglass edging can be used as a sturdier option to film and a good option if a tracking arm is used to detect the edge of the belt when coming in to contact with it.

•  PTFE Coated Kevlar - This is the most durable of the edging types and is a good option when the edge of the belt will be in contact with tracking aids. It is also a good option when considering using tracking studs of cord on the belt.

Specification
